12-Unit Pre-pressized Machine for Shear Test
Model: ZYY-3 Name: Pre-pressized Apparatus for Shear Test
Applications
the product is used to perform pre-pressure working before doing shear test , using the Shear Apparatus, can reduce the test time largely ,
Parameter
Model | ZYY-3 |
Name | Pre-pressized Apparatus for Shear Test |
Max vertical load | 400KPa |
Vertical loading mode | By weigh |
Vertical load grade | 50KPa, 100KPa, 200KPa, 300KPa, 400KPa |
Lever ratio | 1:12 |
Max load force | Max. 1.2KN |
Sample area(cm²) | 30cm², height 2 CM 61.8mm Dia × 20mm Height |
Sample No | 12pcs |
Power source | 220V±10%, 50Hz 100W |
Packed details | |
Net Dimension(mm) | 760 x 880 x 1100(LxWxH) |
Net Weight | 220 Kg |
Case No | 1 |
